Ice fingers, Yosemite NP, CA, USA

Ice fingers, Yosemite NP, California. 400mm, 1 second at f/16, ISO 100; 18 focus-stacked frames blended with Helicon Focus Pro. I needed to photograph this detail at an angle to get the orange reflections, requiring focus-stacking to get everything sharp. (It’s a reflection of a cliff lit by the setting sun.)

Last Thursday, Friday, and Saturday two smaller storms moved through the Sierra, bringing rain and higher-elevation snow. But for a couple of weeks before that it had been dry and warm – reaching the upper 60s at our house in Mariposa.

Early last week, as we were starting our workshop in Yosemite Valley, temperatures cooled off a bit, allowing ice to form along the banks of the Merced River. It’s always fun to photograph ice like this, with its beautiful patterns, designs, and colors. But it can be challenging, both technically and creatively.

I think the creative challenge is mostly about finding strong, effective compositions. With any subject I’m often urging workshop students to simplify and tighten up their compositions – to figure out what’s essential, and pare the photograph down to that. What’s catching your eye the most? How can you eliminate everything else but that, so the remainder has maximum impact? With ice it seems even more important to get in close. Really close. The smallest details are often the most compelling.

And any composition – whether of a big scene or a small detail – is more effective if it has a strong design. That means emphasizing repeating patterns, or interesting lines or shapes. It means creating a design in the photograph, rather than just presenting a subject.

I think some photographs are more subject-driven, but design still plays a vital supporting role. Other photographs are less about the subject itself, and more about design, light, and (maybe) color. I think ice often falls into that latter category; the best ice photographs are not so much about the ice itself, but about the patterns and designs in the ice.

The technical challenge with ice is getting it all in focus. It’s relatively easy to get everything in focus when looking straight down on the ice, so that the ice is parallel to the film or sensor. But in Yosemite Valley, I’m often looking for situations where the ice is in the shade, reflecting sunlit cliffs across the valley. Those sunlit cliffs create beautiful gold or even orange reflections in the ice or surrounding water. However, you won’t see those colors looking straight down, where the ice is reflecting the sky directly above; you only see those colors at an angle, looking toward the reflection of a cliff. And because you’re trying to pick out a small, interesting detail with a long lens, the depth of field is very shallow. Even at f/16 or f/22 it’s impossible to get everything in focus with one frame in those situations. So that means focus-stacking.

Luckily, the ice usually isn’t moving, making focus-stacking easier. Many newer cameras have automated focus-stacking (often called “focus bracketing” in the camera menu). You can focus on the closest thing to the camera (usually at the bottom of the frame with ice images), activate the automated focus bracketing, and the camera will take a series of images at farther and farther focus distances. (You still have to figure out the right settings for this: the increment and number of frames.)

If you don’t have automated focus-stacking you’ll have to do it manually. Start by focusing on the closest part of the scene to the camera (again, usually at the bottom of the frame with ice images), and then focus a little farther back, then a little farther back again, and so on, until you’re focused on the farthest objects the picture. You can do this with manual focus, or by moving your autofocus point to different places in the frame.

It’s possible to use a fairly wide aperture for this, like f/8. But the wider the aperture, the less depth of field, and the less focus overlap between frames, so you’ll need to capture many more frames to get everything in focus from front to back. I prefer to stop down the aperture to f/16 so that I can use fewer frames, which takes less time, occupies less space on my hard drives, and reduces the chances for error. (If there’s not enough overlap there’ll be a gap where part of the image isn’t in focus on any frame.)

You can use Photoshop to blend a focus-stacking sequence, but I much prefer the Pro version of Helicon Focus. (It’s on sale right now. No, I don’t get a commission.) In many situations, Helicon Focus does a better job than Photoshop of blending the images – of selecting the sharpest frame for each part of the photo. The Pro version also has retouching, which can be useful for eliminating ghosting with moving subjects. Best of all, the Pro version allows you to export images from Lightroom to Helicon as DNGs, then save the resulting blended image as a DNG. So you can process that blended DNG like any other raw file, with all the power and flexibility that provides.

Despite the challenges, I love photographing ice. It’s just water, the most abundant substance on our planet’s surface – but water turned into natural crystals, with beautiful patterns and textures that reflect the colors of the world. It’s wonderful stuff.

— Michael Frye

Cottonwood leaves encased in ice, Yosemite NP, CA, USA

Cottonwood leaves encased in ice, Yosemite NP, California. 247mm, 1 second at f/16, ISO 100; Seven focus-stacked frames blended with Helicon Focus Pro. This was looking more straight down, but still at an angle, requiring focus-stacking to get everything sharp.

Ice and reflections, Yosemite NP, CA, USA

Ice and reflections, Yosemite NP, California. 400mm, 1/3 sec. at f/16, ISO 100; 34 focus-stacked frames blended with Helicon Focus Pro. I positioned the camera low to the ground (maybe 18 inches high) to get the gold reflections. Looking across the ice at such a low angle required many frames to get it all in focus.
